Octagonal Steel Tubular Pole Galvanised Steel For Electrical Power Transmission Line

Octagonal Steel Tubular Pole Galvanised Steel For Electrical Power Transmission Line

  • Octagonal Steel Tubular Pole Galvanised Steel For Electrical Power Transmission Line
Octagonal Steel Tubular Pole Galvanised Steel For Electrical Power Transmission Line
Ürün ayrıntıları:
Place of Origin: China
Marka adı: JSHG
Sertifika: ISO/CNAS/IAF/CA
Model Number: HG-SP-13.8KV
Ödeme & teslimat koşulları:
Minimum Order Quantity: One 40 HQ Container
Fiyat: negotiation
Teslim süresi: 1 hafta
Payment Terms: L/C, T/T or Western Union
Supply Ability: 3,000 Metric Tons per Month
İletişim
Detaylı ürün tanımı
Voltage Grade: 13.8KV Welding: According to AWS D 1.1, CO2 welding or submerged arc auto methods
Shape: Conical / Tubular / Tapered Connection Structure: Overlap / Flangeconnection
Application: Electrical Power Transmission Line Appearance Treatment: Appearance Treatment
Vurgulamak:

galvanized steel poles

,

galvanised steel poles

Yield Strength 345Mpa 69KV Galvanized Octagonal Steel Tapered Pole



Specifications:



Products

  • Yield Strength 345Mpa 69KV Galvanized Octagonal Steel Tapered Pole

Type

  • Suspension Pole , Tensile Pole , Strain Pole , Angle Pole , Dead-end Pole , etc

Voltage Grade

  • 13.8KV
  Height
  • 25FT , 30FT , 35FT , 40FT , 45FT , 50FT , 55FT , 60FT , etc.

Shape

  • Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc),Tubular, Tapered

Material

  • Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65 and others equivalent steel material

Wall thickness

  • 2 ~ 6mm

Once Forming

  • 16m Once forming without joint

Welding

  • Welding complies with AWS D1.1 standard.
  • Internal and external welding makes the pole more beautiful in shape
  • CO2 welding or submerged arc auto methods
  • No fissure, scar, overlap, layer or other defects
  • If customers need any other requirements of welding, we also can make adjustment ad your request

Joint

  •  Joint with insert mode, flange mode.

Base plate

  • Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.

Galvanization

  • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.

Painting

  • According to clients' request

Life Period

  • More than 25 years, it is according to installing environment

Advantages

  • Short Construction Cycle
  • Low Overall Cost
  • Less Land Occupation
  • Weather Resistance
  • Easy Installation and Maintenance
  • Anti-corrosion
  • ODM & OEM are available
  • Capable to Handle Volume Orders
  • Provide Professional Design by Our Experienced R&D Engineers





Our Services

  • Reply within 24 Working Hours
  • Capable to Handle Volume Orders
  • More than 15 Years Design & Manufacture Experience
  • ODM, OEM Acceptable
  • High-Quality and Low-Price Products
  • Factory Direct Sale
  • Provide Professional Design by Our Experienced R&D Engineers
  • Rich Exporting Experience
  • Technical Support by E-mail
  • Calling service


Please feel free to contact us!


Hot Dip Galvanized Steel Tubular Pole for Electrical Power Transmission and Distribution Line, Outdoor Lighting Project, Telecommunication Industry, Traffic System, Wind Power Project.pdf







Engineering and Design Management



“Design and technology,professional and common, software and hardware” is JSHG‘s design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.



In the R&D Department, there are many experienced senior research & design staff and rigid development network, which ensure our design proposals meet customer demand, even exceed their expectations.
